Heart (Hippocratic Corpus)

See the digital model and analysis on the
ATLAS
⁠
⁠

Περὶ καρδίης (De corde)
Search
Membranes and Other Things
A - light-coloured membranes (veils of the mitral valve) B - light-coloured web-like cords (chordae tendieae) C - deep-coloured ktēdones (papillary muscles and trabeculae carneae). D - walls of the left cavity
View into Two Cavities
L - view into left ventricle; parts of the atrium were left in place (e.g. marked by the L) R - view into right ventricle; parts of the atrium were left in place (e.g. marked by the ) Ao - Aorta
Orifices (stomata) of the Heart
Membranes and Other Things
A - light-coloured membranes (veils of the mitral valve)
B - light-coloured web-like cords (chordae tendieae)
C - deep-coloured ktēdones (papillary muscles and trabeculae carneae).
D - walls of the left cavity
Info
Porcine heart. Left cavity. June 2024.
Membranes and other things.jpg
⁠
